Model |
Dimension |
Basic Load Roting |
Balls |
Limiting Speed (r/min) |
Weight (approx.) |
|||||
| d | D | B | Cr | Cor | Qty | Dia. |
Grease |
Oil |
g | |
| mm | mm | mm | N | N | PCS | mm | ||||
| 16001 | 12 | 28 | 7 | 5090 | 2360 | 8 | φ4.763 | 28000 | 32000 | 15 |
| 16002 | 15 | 32 | 8 | 5590 | 2860 | 9 | φ4.763 | 24000 | 28000 | 23 |
| 16003 | 17 | 35 | 8 | 6000 | 3270 | 10 | φ4.763 | 22000 | 26000 | 28 |
| 16004 | 20 | 42 | 8 | 7920 | 4445 | 10 | φ5.556 | 18000 | 20000 | 52 |
| 16005 | 25 | 47 | 8 | 8850 | 5630 | 12 | φ5.556 | 15000 | 18000 | 59 |
| 16006 | 30 | 55 | 9 | 11260 | 7355 | 12 | φ6.350 | 13000 | 15000 | 84 |
